VCDS® Premium Professional Kit
The Ross-Tech VCDS® with HEX-NET® Pro is not an OE-tool but... in some ways it's better than the OE tool and is inexpensive enough to be a must-have tool for any technician that works on VAG models 1995 to current.
* Independent Repair Shops
* Dealership Technicians
* Transmission Specialists
* Locksmiths
Its VCDS and VCDS-Mobile software surpasses all other aftermarket tools and rivals the factory tool at a fraction of the cost!
Its HEX-NET Pro hardware includes an embedded license for both the PC-based VCDS and smart-device based VCDS-Mobile.
The VCDS® Professional Kit with HEX-NET® Pro is not VIN-limited, includes a heavy-duty storage case and 15 Tickets for live telephone tech support from Ross-Tech.
Capabilities
Performs all necessary EPB functions in VAG models!
Use the SRI Reset function to reset the Service Interval Reminder (SRI) on Audi and VW. The Service Interval Reminder (SRI) may include oil mileage interval, the service mileage interval, and the service time interval.
The depth you expect from an OEM-level tool:
* Compatible with all diagnostic-capable VW/Audi passenger cars from 1995 to current; K, K+L, dual-K, or CAN.
* Factory level access to all modules
* Comprehensible DTC Descriptions
* Labelled and Searchable MVB Data
* Basic Settings with Descriptions
* Service Reminder Reset
* Database of more than 9200 fault-codes and measuring-block texts.
* Uses 7-Digit PIN/SKC codes to match new keys in all immobilizer equipped models.
* Alter settings normally accessible only to dealerships
* Code replacement modules and select options
* Log and graphs 3 groups of Measuring Blocks at once
* View and log live data
* Accesses all control modules which require proprietary VAG modes running KWP-2000 protocols (2001+ Teves Mk.60 ABS, numerous 2002+ modules)
* Displays critical timing information on TDI engines in graphic form
The VAG-COM Diagnostic System (VCDS) also does one thing the factory tool does not: Logging of live data for later analysis. It is also faster and easier to use than the factory tool, even technicians at VW of America use this tool rather than the factory tool.
Features
• Connects via WiFi or USB
• Includes an embedded license for VCDS and VCDS-Mobile software
• Windows-based VCDS software connects via WiFi or USB
• Browser-based VCDS-Mobile software connects via WiFi to most smart devices and desktop/laptops
• 32-bit micro-controller and fully updateable firmware.
• Three bi-color (red/green) satus/activity LEDs
• 12 month guarantee against defects in workmanship or materials.
• Free software updates via the web
Coverage
HEX-NET® Pro hardware is not VIN-limited and is compatible with all diagnostic-capable VAG passenger cars from 1995 to current; K, K+L, dual-K, or CAN, and UDS/ODX.
Optional adapter available separately for 1990-1995 pre-OBDII vehicles with the 4-wire 2×2 port.
It will work with "chipped" vehicles if the chip-vendor did nothing that interferes with diagnostic functions.
System Requirements
VCDS PC-based software: requires a 1.5 GHZ dual core processor with 1 Gb of RAM and Windows 7 or newer (Windows 7 through 10, but not RT) with an available USB 2.0 (or higher) port. Using a PC that is robust enough to properly support the operating system of the computer is robust for VCDS. Not Supported: Windows running inside a Virtual Machine (for example on a Mac).
VCDS-Mobile browser-based software: requires devices with WiFi and modern browser. Compatible with:
Desktop/Laptops - MacOS, Linux, and Microsoft Windows® versions from Windows XP to current.
Smart Devices - Apple iPad®, iPhone®, etc, most Android® phones and tablets, Blackberry Z10®, Q10®, etc., Microsoft Surface® & Windows Phone®, KindleFire®, etc.
Contents and Tech Support
(2) HEX-NET Pro Wifi & USB Interface for VCDS and VCDS-mobile
(2) USB A-to-B detachable Cable w/screw lock (2m)
(2) Right Angle OBD-II DLC extension (6-ft)
(1) 2×2 adapter for older cars
(1) Heavy Duty Carrying/Storage Case
(1) USB Flash Drive w/VCDS program
(1) Getting Started Manual
(1) 15-ticket Annual Live Telephone Tech Support Plan
Free software updates
Free Support via Email, Forum, Wiki
One-year warranty on hardware
WiFi configuration support is only provided via the Ross-Tech Support Forum, in English only.
Product Support
- The HEX-NET Pro is fully supported by Ross-Tech via e-mail or over the phone as a USB interface for VCDS.
- WiFi configuration support is only provided via the Ross-Tech Support Forum, in English only.
