Universal Secondary Test Lead Kit for COP, DIS, HEI, Dist for the uScope
Regular price
$79.00
The Universal Secondary Test Lead Kit combines the two most popular styles of secondary leads into one, for complete coverage on COP, DIS, HEI, Dist.
One end of the secondary lead attaches to the uScope®, the other end connects to either the:
- traditional T-clamp most usually placed over the plug wire.
- flexible paddle which makes secondary COP a quick and easy test. Coil construction can prevent capturing a waveform with any paddle probe. 4-wire and some 3-wire coils will not produce usable waveforms.
Test Lead Configuration
- Connection to scope: The test lead connects to the uScope channel input.
- Connection to vehicle: Two connections are made at the vehicle: one for Ground and one for signal using either the T-clamp or Paddle.
| Characteristics of the Universal Secondary Kit (AES# 01-10): | |
|---|---|
| Attentuation: | 1000:1 |
| Connection at Scope: | "micro-BNC" connects to the uScope® |
| Cable: | RG174, Shielded |
| Color: | Black |
| Length: | 6-feet |
| Connection at vehicle: |
Ground: Wide jaw, chrome-plated gator 2ndary Clamp: Wide jaw, chrome-plated T-clip 2ndary Paddle: Insulated rod terminating to a flat, flexible probe |
